Tracy NN Documentation
What is Tracy NN:
Tracy NN is a debugger tool for better understanding the matrix operations in pytorch deep learning library. Honestly I’m bad at Linear Algebra and it gets very difficult & frustrating to follow complicated architectures like transformers and truly internalize the events and operation that are happening in there.
So while working on my own project i came up with the idea and really used the help of pytorch hook functions to log the Tensor shapes being transormed by the operation or nn.Modules.
I hope it becomes a useful tool for everyone to better understand deep learning.
How to install it:
1
pip install tracy_nn
How to use it:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
import torch
import torch.nn as nn
from tracy_nn import Tracer
# Make a dummy input tensor (or not dummy. you decide!)
x = torch.rand(batch_size, seq_len, d_in)
# Create an instance of your Module
mha = MHA(d_in, d_out, seq_len, num_heads, context_window, dropout)
# Create an instance of tracer and name it (use the name of what's being traced)
tracer = Tracer('MHA')
# Start the tracing process
tracer.start(mha)
# One forward pass is enough for the tracing process
output = mha(x)
# Stop the tracing process
tracer.stop()
Tracy NN even provides easier ways:
1
2
3
from tracy_nn import Tracer
with tracer.trace(model):
output = model(input_tensor)
or:
1
2
3
4
from tracy_nn import trace_model
tracer = trace_model(model, 'My Model')
with tracer.trace(model):
output = model(input_tensor)
Result:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
● TRACING MHA STARTED
│
● query_weights (Linear) (in_features: 6, out_features: 6)
├─ Input: Tensor [10, 20, 6] @ cpu
└─ Output: Tensor [10, 20, 6] @ cpu
│
● key_weights (Linear) (in_features: 6, out_features: 6)
├─ Input: Tensor [10, 20, 6] @ cpu
└─ Output: Tensor [10, 20, 6] @ cpu
│
● value_weights (Linear) (in_features: 6, out_features: 6)
├─ Input: Tensor [10, 20, 6] @ cpu
└─ Output: Tensor [10, 20, 6] @ cpu
│
● Tensor.view(10, 20, 3, 2) @ [MHA.split_heads]
├─ Input: Tensor [10, 20, 6] @ cpu
└─ Output: Tensor [10, 20, 3, 2] @ cpu
│
[...]
│
● Tensor.@ @ [MHA.calculate_attention]
├─ Left: Tensor [10, 3, 20, 20] @ cpu
├─ Right: Tensor [10, 3, 20, 2] @ cpu
└─ Output: Tensor [10, 3, 20, 2] @ cpu
│
● Tensor.transpose(1, 2) @ [MHA.combine_heads]
├─ Input: Tensor [10, 3, 20, 2] @ cpu
└─ Output: Tensor [10, 20, 3, 2] @ cpu
│
● Tensor.view(10, 20, 6) @ [MHA.combine_heads]
├─ Input: Tensor [10, 20, 3, 2] @ cpu
└─ Output: Tensor [10, 20, 6] @ cpu
│
● out_projection (Linear) (in_features: 6, out_features: 6)
├─ Input: Tensor [10, 20, 6] @ cpu
└─ Output: Tensor [10, 20, 6] @ cpu
│
● TRACING MHA COMPLETE
Note:
Don’t use tracy nn while training, logs will fill your terminal and slow the training process, tracy is meant to be used at designing & debugging process. that’s why only one forward pass will be enough.
Some operations like torch.cat() don’t get logged so better to use the equivalent methods like Tensor.cat(), but don’t worry most operations, even python standard operations like @, and / are coverd by translation to their torch equivalent.
